KP-802 Printer
The KP-802 Printer is a direct thermal receipt printer designed with a blazing print speed of 260mm/s and 203 dpi resolution, it ensures crisp and reliable output for both text and graphics. Compatible with 58mm and 80mm paper widths and a maximum print width of 80mm, it adapts tovarious receipt formats. Its compact footprint,30% smaller than traditional models,fits easily into limited counter space,while the 2MB input bufferand 256KB NV Flash enable smooth,efficient data processing. Multiple connectivity options ensure seamless integration with modern POS systems.
<
>
features
Forward paper
output
output
82mm big paper
bin
bin
150KM printer
head life
head life
2 million times
cutter
cutter
260mm/s high
speed print
speed print
specifications
|
SPECIFICATION
|
KP-802 Printer | |||
| Model | KP-802 Printer | |||
| Printing | Print Method | Direct Thermal | ||
| Print Speed | 260mm/s | |||
| Resolution | 203dpi | |||
| Printing Width | 72mm(default) 80mm(Max) | |||
| Discharge direction | "Top paper"and "front paper"can be adjusted in both directions | |||
| Paper separator(option) | 58mm (57.5±0.5mm) 80mm(79.5±0.5mm) | |||
| Interface | USB+LAN/USB+LAN+WIFI/BT(optional) | |||
| Page Mode | Support | |||
| Memory | Input buffer | 2M | ||
| NV Flash | 256kbytes | |||
| Fonts | Font A | 12×24 | ||
| Font B | 9×17 | |||
| Chinese | GB18030,BIG524×24dots | |||
| Character Size(mm) | Font A:15×3.0mm;Font B:11×2.1mm;Simple/Traditional:3.0×3.0mm | |||
| Japanese/korea | Japanese JIS, Korean KSC5601(Optional) | |||
| User-defined | Support | |||
| Barcode | 1D | UPC-A/UPC-E/JAN13(EAN13)/JAN8(EAN8)/CODE39/ITF/CODABAR/CODE93/CODE128 | ||
| 2D | PDF417,QR code | |||
| Detection | Sensors | Lack of paper detection,open cover detection,overtemperature detection | ||
| Power Supply | Input | AC 100V-240V 50/60Hz | ||
| Output | DC 24V/2.5A | |||
| Paper | Paper Type | Thermal Receipt Paper | ||
| Paper Width | 58mm(57.5±0.5mm) 80mm(79.5±0.5mm) | |||
| Paper Thickness | 0.04-0.08mm | |||
| Roll Dia | Max.Ø82 mm | |||
| Paper Load | Easy paper loading | |||
| Paper Cut | Auto-cutter(half cut) | |||
| Physical Characteristics | Working Condition | 5℃-45℃,10%-90%RH | ||
| Storage Condition | -20℃-60℃,10%-90%RH | |||
| Dimensions | 128(D)×129(W)×132.6(H)mm | |||
| colour | All Black,white gold,Black gold (default) | |||
| Net weight | 1kg | Gross weight | 1.7kg | |
| Reliability | Printing head | 150KM | ||
| cutter | 2million | |||
| Accessories | USB data cable,Power adaptor,Power cord,Paper roll,CD,Manual,Paper separator. Serial cable (optional) | |||
| Packing | Individual box | Dimension 23×15.5×14.4cm(L×W×H) | 1 unit/carton | |
| Master carton | Dimension 48×31×49cm(L×W×H) | 12 units/carton | ||
| OS | Emulation | ESC/POS | ||
| Driver | Windows XP Nista/Win7/Win8 Min10/Win11/Win | |||
| SDK | 2000/WINCE/OPOS/JPOS | |||
| Safety standard | CCC/ROHS/CE | |||
